Jest 29 produktów.

Pokazano 1-24 z 29 pozycji

Aktywne filtry

The HDK-55 is a high performance full digital HDTV camera with superb picture quality and system versatility for studio and field production.

Newly developed FPGA with advanced full digital process ASIC
The HDK-55 incorporates a newly developed FPGA together with advanced full digital process ASIC to achieve outstanding picture performance.
Lens Aberration Correction function
The Lens Aberration Correction function is newly incorporated for minimizing the blur and colored edges caused mainly by lens chromatic aberration.

2/3-inch 2.3 Mega pixel AIT CCDs
2/3-inch 2.3 Mega pixel AIT CCDs are employed to achieve 1000 TVL horizontal resolution with excellent signal to noise ratio of 60dB at F10 (1080/59.94i) or F11 (1080/50i) sensitivity.
Docking style camera body
With a docking style camera body, either an FA (Fiber Adaptor) or TA (Triax Adaptor) can be mounted depending on the use.

2 Channels QTV
Two channels of QTV output (VBS) are available for prompter and external monitoring purposes. The AUX OUT (VBS) connector can be assigned to QTV-1, QTV-2, or Main video by menu. Note:BS/CCU should support 2 channels of QTV.
Sophisticated features made possible with digital technology
The Fine Detail (DTL) function makes the picture more realistic by compressing the detail edge component when shooting high contrast scenes. Highlight DTL and several other DTL functions are also available.

Camera Operator Assist Functions
There are two types of camera operator assist functions incorporated in the HDK-55 camera head. The viewfinder detail(VF DTL) function allows the camera operator to increase the detail edges to the viewfinder video for easy-focusing. In addition, the Quick EZ Focus (Focus Assist) function is newly incorporated useful tool, providing very distinct enhancement to the viewfinder edge signal to enable the camera operator to make critical focus adjustment.
Video processing technology to maximize the benefit of 16-bits
This camera is designed from the start based on 16-bit A/D and matching 16-bit DSP to maximize the benefits of high bit quantization. Especially for the dark areas of the picture, the higher gradation for gamma and other circuits improves the reproduction, providing for more natural color in the shadow areas of the picture.

Variety of Viewfinders
For the HDK-55, 2-inch 16:9 high definition VFs for portable application are available, including monochrome CRT type and color LCD type. In addition, 5-inch CRT, 7-inch LCD and 9-inch LCD color viewfinders are also available as options.
SE-H700 System Expander
The SE-H700 System Expander enables the use of the 9-inch viewfinder and full studio lenses with the HDK-55, converting the portable camera into a full facility studio camera. Installation of the camera into the SE-H700 is easy, and conversion back to portable configuration is quick for maximum operating flexibility.

Affordable Camera Control Unit
The BSF-55 is newly designed in the compact size of 1.5RU height with 19-inch rack mount width, transmitting uncompressed high quality pictures with use of an optical fiber connection between HDK cameras. Both HDTV and SDTV formats are supported simultaneously in both digital and analog form with a wide range of built-in interfaces. The BSF-55 also features embedded audio in the SDI output signals. A half-rack base station, BS-89A, is also available, permitting full SMPTE fiber cable extension with a compact base station, suitable for small sized OB vans and rental / flight-pack systems. The BS-89A supports 2 channels of QTV to match the camera head feature.
Sophisticated Camera Control Panel System
There are two types of camera control panel systems, each with a wide range of camera control capability. The conventional OCP allows direct and quick control of various camera parameters using dedicated buttons on the panel. The OCP-200 / MCP-200 Network based control panel system allows any OCP to control any camera with assignment set at the OCP itself. System wiring is simplified with control of up to 96 cameras via a single coax cable between CCU locations and video control locations. The OCP-200 and MCP-200 include touch screen LCDs. The depth-of-control of the OCP-200 can be selected from basic to complete to fit the customers' operating discipline. Conventional one by one camera control connection is also available with the OCP-200.



Scanning System 1080/59.94i, 1080/50i
Image Sensor2/3-inch 2.3 million pixel AIT CCD
Optical System 2/3-inch RGB prism, f1.4
Filter
 1234
ND100%25%6.2%1.6%
 ABCD
ECC3200K4300K6300K8000K
Sensitivity F10 (1080/59.94i) / F11 (1080/50i) typical at 2000 lx (White reflection 89.9%)
S/N Ratio 60dB typical (HDTV)
Limiting Resolution 1000TV lines
Gain -6,-3, 0, +3, +6, +12, +18dB
Electric Shutter 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000
Operating Temperature-20°C to +45°C(-4°F to -113°F)
Operating Humidity30% to 90% (non-condensing)
Operating VoltageDC +11 to +16V
Weight4.5Kg (9.92 lbs ) with FA-55
Dimensions W138.5 x H270 xD337 mm (W5.45 x H10.63 x D13.27inch) Approx. (excluding protrusions) (with FA-55)
Power ConsumptionApprox. 20W (without FA-55)
Input signals
External Sync SignalSYNC 0.6Vp-p ±6dB 75ohm BNC type 1ch
Audio Signal-60 to +4dB(Variable)/ -20dB (Fixed) XLR type 2ch (600ohm balanced)
Intercom Signal XLR type or 110 type 2ch
Output signals
Main Video Signal Y,Pb,Pr 4:2:2 serial digital, Fiber op
SDI OUT HD-SDI, BNC type 1ch
MON SDI HD-SDI, BNC type 1ch (VF, RET, or Main video selectable by menu)
Q-TV VBS signal, BNC type 1ch (QTV or Mon video (HD-Y signal) switch selectable)
AUX OUT VBS signal, BNC type 1ch (QTV-1, QTV-2, or Main video selectable by menue)
DC OUT+12VDC 500mA (max), 4-pin type 1ch
Ikegami HDK-55

Ikegami HDK-55

16-bit Full Digital HDTV Portable Camera System
Cena Zapytaj o cenę!


■ Super High Sensitivity [0.001lux]
Under starlight condition(0.001lux/F1.4), it can produce color video(60fps).
■ Camera Operator Assist Function
There are two types of camera operator assist functions incorporated in the HDK-5500 camera head. The viewfinder detail(VF DTL) function allows the camera operator to increase the detail edges to the viewfinder video for easy-focusing. In addition, the Quick EZ Focus(Focus Assist)function is newly incorporated useful tool, providing very distinct enhancement to the viewfinder edge signal to enable the camera operator to make critical focus adjustment.

■Lens Aberration Correction Function
The Lens Aberration Correction Function is newly incorporated for minimizing the blur and colored edges caused mainly by lens chromatic aberration.









Scanning System 1080/59.94i, 1080/50i
Image Sensor 2/3-inch 1.3 million pixel CMOS
Optical System 2/3-inch RGB prism, F1.4
Optical Filter
  1234
ND 100% 25% 6.2% 1.6%
  A B C D
ECC 3200K 4300K 6300K 8000K
Sensitivity F22 or more at 2,000lux
Minimum Illumination 0.001 lux (value in theory) +78dB [gain up, 100% video level]
S/N Ratio 56 dB or more
Limiting Resolution 700 TV lines
Gain -6/0/6/12/18/24/30/36/42/48/54/60/66/72/78dB
Electric Shutter 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000
Operating Temperature -20 °C to +45 °C
Operating Humidity 30% to 90% (non-condensing)
Power Requirement DC +11V to +16V
Weight 4.5kg with FA-55
Dimensions W138.5 × H270 × D337mm (excluding protrusions)[with FA-55]
Ikegami HDK-5500

Ikegami HDK-5500

Super High Sensitivity 3CMOS HDTV Portable Camera System
Cena Zapytaj o cenę!
• Employs high performance CMOS image sensors for superb picture quality
• Incorporates newly developed FPGA for video DSP
• Compact docking style camera body, fiber and triax adapters
• Single format: 1080i or 720p (1 format standard, 2nd option)
• Lens Aberration Correction function
• Camera Operator Assist Functions

Next generation 2.5 Mega pixel high performance CMOS sensors
The camera employs 2.5 Mega pixel 2/3-inch CMOS image sensors, achieving superior quality HDTV video with horizontal resolution of 1000TVL, SNR of 60dB or more, and sensitivity of F11.
Newly developed FPGA DSP
High density 45nm rule FPGA are employed for the digital video processing for superb picture quality. And the DSP includes custom gamma curves (cine gamma).

Lens Aberration Correction function
A Lens Aberration Correction function is newly incorporated for minimizing the loss of resolution and colored edges caused mainly by lens chromatic aberration.
Camera Operator Assist Functions
The HDK-65C camera head incoporates a camera operator assist function to aid the operator finding correct focus. The viewfinder detail (VF DTL) function allows the camera operator to increase the detail edges to the viewfinder video for easy focusing.

Two HD-SDI outputs from the camera head
Two HD-SDI output signals (1.5G) are selectable between Camera, VF, RET and MON (monitor) for external monitoring at the camera head.
Docking style camera body
With a docking style camera body, either an FA (Fiber Adaptor) or TA (Triax Adaptor) can be mounted depending on the use. A new lower profile and lower weight improve the manuverability for shoulder use.

Ikegami HDK-65C

Ikegami HDK-65C

Full Digital HDTV Portable CMOS Camera System
Cena Zapytaj o cenę!
2.6 Mega pixel high performance CMOS sensors
The camera employs 2.6 Mega pixel 2/3-inch CMOS image sensors, achieving superior quality HDTV video with horizontal resolution of 1000TVL, SNR of 60dB or more, and sensitivity of F12.

Newly Developed High Performance Full HD 2/3-inch CMOS Sensors
The HDK-73 utilizes three 2/3-inch 2.6 mega pixel CMOS sensors, each capable of capturing full HD 1920 x 1080 resolution images and a wide dynamic range of more than 600%, and giving you an excellent sensitivity of F12 (60Hz) / F13 (50Hz) and high signal-to-noise ratio.
Native Multi-format
The CMOS sensors support progressive and interlace readout, natively supporting 1080i/59.94 and 1080i/50, as well as 720p/59.94 and 720p/50 HDTV formats.

Advanced Full Digital DSP
This camera is designed from the start base on End-to-End Digital made possible by using CMOS sensors, and includes the benefits of high bit quantization. Especially for the dark areas of the picture, the higher gradation for gamma and other circuits improves the reproduction, providing for more natural color in the shadow areas of the picture. Up to 38-bits are used within the DSP.
Lens Aberration Correction Function
The Lens Aberration Correction function is incorporated for minimizing the loss of resolution and colored edges caused mainly by lens chromatic aberration.

Two HD-SDI Outputs from the Camera Head
Two HD-SDI output signals (1.5G) are selectable between Camera, VF, RET and MON (monitor) for external monitoring at the camera head.
Quick EZ Focus Assist Function
The Quick EZ Focus Assist function is a newly incorporated useful tool, providing very distinct enhancement to the viewfinder signal to enable the camera operator to make critical focus adjustment. The size of area, area color, edge color, and display time on the viewfinder are adjustable in the camera menu.

RET and QTV Channels
The featured base stations for the HDK-73 support four channels of return video (RET), two each for SDI and VBS. The selected channel can be output at the camera as an HD-SDI signal (upconverted if input in SDTV) and used to feed a talent monitor or other purpose. In addition there is a separate prompter channel (QTV) with SDTV input at the base station and SD output at the camera.
Advanced Digital Detail
Both horizontal and vertical Detail Correction circuits for red, green and blue signals are independently and digitally processed. You can obtain the full resolution of a high quality picture with extremely low noise, even under low-light shooting conditions.

Dockable Camera Body
With a docking style camera body, either an FA(Fiber adapter), TA (Triax adapter) or CA (Camera adapter) can be mounted without any external cables depending on the use. A new lower profile and lower weight improve the manuverability for shoulder use.
Moire Reduction Filter (Factory Option)
An Anti-Moire Optical Low-Pass Filter can be fitted in the filter wheel to reduce unwanted moire video patterns when shooting a large LED screen, etc. * If this optional filter is ordered, one of the ND filters must be replaced.

HDR (High Dynamic Range)
The camera provides an HDR function with its HLG (Hybrid Log Gamma) curve. It is now possible to shoot a scene with high dynamic range without lossing gradation in the highlights.


Ikegami HDK-73

Ikegami HDK-73

3-CMOS HDTV Camera System – HDR Ready
Cena Zapytaj o cenę!
The HDK-790GX are high quality multi-purpose high end camera models reproducing the quality of Ikegami’s EX-series cameras, and adding new features and accessories associated with the new Unicam HD series.They can be used for studio, as well as, field applications.

2/3-inch 2.3 Mega pixel AIT CCDs
Three 2/3-inch 2.3 Mega pixel AIT CCDs are employed to achieve 1000 TVL horizontal resolution with high signal to noise ratio of 61dB at F10 (1080/59.94i) or F11 (1080/50i) sensitivity.
Newly developed FPGA with advanced full digital process ASIC
The HDK-790GX incorporates a newly developed FPGA together with advanced full digital process ASIC to achieve outstanding picture performance.

Video processing technology to maximize the benefit of 16-bits
This camera is designed from the start based on 16-bit A/D and matching 16-bit DSP to maximize the benefits of high bit quantization. Especially for the dark areas of the picture, the higher gradation for gamma and other circuits improves the reproduction, providing for more natural color in the shadow areas of the picture.
Advanced features made possible with digital technology
Advanced features such as Master Gain Control, Variable Color Temp., Custom Gamma functions are incorporated.

Digital Extender
There is the selection of x1.5, x2, x3, x4 digital extender available to enlarge the image at the center of shot without any loss in image sensitivity. * It will reduce the resolution of the image.
Lens Aberration Correction Function
The Lens Aberration Correction Function is newly incorporated for minimizing the loss of resolution and colored edges caused mainly by lens chromatic aberration.

2 Channels QTV
Two channels of QTV output (VBS) are available at the camera for prompter and external monitoring purposes. * BS/CCU should support 2 channels of QTV.
HD SDI Trunk
When the camera is operating with CCU-970M, the system allows 3G (1.5G x2) transmission from the camera head to the CCU, and a second 1.5G video can be transmitted to the CCU as a video trunk channel.

Built-in Triple Layer Filter (ND/EFF/ECC)
The triple layer filter system can be remotely controlled from OCP/MCP. The three layers are ND (100%, 25%, 6.2%, 1.6%), EFFECT (Clear, Cross, Snow, Fog) and Electronic Color Compensation (ECC: 3200K/4300K/ 5600K/6300K/8000K).In addition, there is Variable Color Temp. function that enables the camera operator to continuously vary the color temperature from 2,000k to 20,000k for easy and precise adjustment.
Camera Operator Assist Functions
There are two types of camera operator assist functions incorporated in the HDK-790GX camera head.The viewfinder detail(VF DTL) function allows the camera operator to increase the detail edges to the viewfinder video for easy-focusing. In addition, the Quick EZ Focus (Focus Assist) function is a newly incorporated useful tool, providing very distinct enhancement to the viewfinder signal to enable the camera operator to make critical focus adjustment.



Supporting Formats 1080i (59.94Hz or 50Hz) Y,Pb,Pr 4:2:2 Interlaced
1080psf (29.97Hz or 25Hz) Y,Pb,Pr 4:2:2 Interlaced
Image Sensors 2/3-inch 2.3 million pixel AIT CCD
Optical system 2/3-inch RGB prism, f1.4
Lens Mount BTA- S1005B
Filter
 12345
ND 100%25% 6.2%1.6%CAP
 IIIIIIIVV
EffectCLEARCROSS SNOWFOGGYCLEAR
 AB CDE
ECC3200K4300K5600K6300K8000K
Sensitivity F10 (1080/59.94i) / F11 (1080/50i) typical at 2000 lx (White reflection 89.9%)
S/N 61dB typical (HDTV)
Limiting Resolution 1000TV lines
Modulation Depth 50% or more(1080i/59.94Hz)
Variable Color Temperature 2,000k~20,000k variable
Electric Shutter 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000
Detail Correction Vertical : 5 lines Horizonta : Boost frequency: 13MHz~22MHz (HDTV)
Gamma OFF, 0.35, 0.4, 0.45
Gain -6, -3dB, 0dB, +3dB, +6dB, +9dB, +12, +18dB
Operating Temperature -20℃ ~ +45℃ (-4°F ~ 113°F)
Operating Humidity 30% ~ 90% (Non-condensing)
Operating Voltage AC100/110/117/220/240V ±10%
Weight Approx 24kg (52.9lbs)
Dimensions W315 x H328 x D398mm (excluding VF),
(W12.37 x H12.87 x D15.62 inches)
Input Signals
External Sync Signal SYNC 0.6Vp-p ±6dB 75ohm 1ch
Audio Signal -60dB ~ +4dB (Variable) / -20dB (Fixed) 2ch (600 ohm Balanced)
Intercom Signal XLR Type or 110 Type CN 2ch
Video Trunk Serial Digital 75 ohm 1ch (Option) *Option and BS/CCU must support Video Trunk.
Output Signals
HD SDI Signal Serial Digital 75 ohm 1ch
Q-TV Signal VBS signal 1ch Standard
or VF / RET / MON / HD-QTV (MENU Selection) Serial Digital 75 ohm BNC 1ch
(Factory Option)
*Optional HD-QTV(Trunk) module should be installed in the CCU.
VBS signal 2ch
*Option and BS/CCU must support 2 channels of QTV.
MON Video Signal VF / RET / MON (MENU Selection) Serial Digital 75 ohm BNC 1ch
HD QTV Serial Digital 75 ohm 1ch (Option)
*Optional HD-QTV(Trunk) module must be installed in the CCU.
Intercom Signal 0 dBs 4ch (ENG/PROD/PGM1/PGM2), XLR Type or 110 Type CN
DC Output +12VDC 500mA (max), 4-pin type 1ch
Ikegami HDK-790GX

Ikegami HDK-790GX

State-of-the-Art 16-bit Full Digital HDTV Camera System
Cena Zapytaj o cenę!
The HDK-79GX is a state of the art full digital HDTV camera with superior picture quality and high reliability for studio and field HD production.

Newly developed FPGA with advanced full digital process ASIC
The HDK-79GX incorporates a newly developed FPGA together with advanced full digital process ASIC to achieve outstanding picture performance.
Lens Aberration Correction function
The Lens Aberration Correction function is newly incorporated for minimizing the blur and colored edges caused mainly by lens chromatic aberration.

2/3-inch 2.3 Mega pixel AIT CCDs
2/3-inch 2.3 Mega pixel AIT CCDs are employed to achieve 1000 TVL horizontal resolution with excellent signal to noise ratio of 61dB at F10 (1080/59.94i) or F11 (1080/50i) sensitivity.
Docking style camera body
With a docking style camera body, either an FA (Fiber Adaptor) or TA (Triax Adaptor) can be mounted depending on the use.

2 Channels QTV
Two channels of QTV output (VBS) are available for prompter and external monitoring purposes. The AUX OUT (VBS) connector can be assigned to QTV-1, QTV-2, or Main video by menu. Note:BS/CCU should support 2 channels of QTV
Advanced features made possible with digital technology
Master Gain Control, Variable Color Temp., Custom Gamma functions are newly incorporated by using advanced digital technology, providing favorable images with flexible adjustments.

Camera Operator Assist Functions
There are two types of camera operator assist functions incorporated in the HDK-79GX camera head. The viewfinder detail(VF DTL) function allows the camera operator to increase the detail edges to the viewfinder video for easy-focusing. In addition, the Quick EZ Focus (Focus Assist) function is newly incorporated useful tool, providing very distinct enhancement to the viewfinder edge signal to enable the camera operator to make critical focus adjustment.
Video processing technology to maximize the benefit of 16-bits
This camera is designed from the start based on 16-bit A/D and matching 16-bit DSP to maximize the benefits of high bit quantization. Especially for the dark areas of the picture, the higher gradation for gamma and other circuits improves the reproduction, providing for more natural color in the shadow areas of the picture.

Triple Layer Filter (ND/EFF/ECC)
The triple layer filter system can be remotely controlled from OCP/MCP. The three layers are ND (100%, 25%, 6.2%, 1.6%), EFF (Clear, Cross, Snow, Foggy), and Electronic Color Compensation (ECC: 3200K, 4300K, 5600K, 6300K, 8000K). In addition, there is the Variable Color Temp. function that enables the camera operator to variably control the color temperature from 2,000K to 20,000K for more precise adjustment at ease.
SE-H700 System Expander
The SE-H700 System Expander enables the use of the 9-inch viewfinder and full studio lenses with the HDK-79GX, converting the portable camera into a full facility studio camera. Installation of the camera into the SE-H700 is easy, and conversion back to portable configuration is quick for maximum operating flexibility.

Digital Extender
The HDK-79GX features the Digital Extender function that instantly goes up to 4x to enlarge the image at the center of shot without any loss in image sensitivity. * It will reduce the resolution of the image.
Sophisticated Camera Control Panel System
There are two types of camera control panel systems, each with a wide range of camera control capability. The conventional OCP allows direct and quick control of various camera parameters using dedicated buttons on the panel. The OCP-200 / MCP-200 Network based control panel system allows any OCP to control any camera with assignment set at the OCP itself. System wiring is simplified with control of up to 96 cameras via a single coax cable between CCU locations and video control locations. The OCP-200 and MCP-200 include touch screen LCDs. The depth-of-control of the OCP-200 can be selected from basic to complete to fit the customers' operating discipline. Conventional one by one camera control connection is also available with the OCP-200.



HDK-79GX with FA-97 or FA-55
Supporting Formats 1080/59.94i, 1080/50i,1080/29.97pasf, 1080/25psf
Image Sensor 2/3-inch 2.3 million pixel AIT CCD
Optical System 2/3-inch RGB prism, f1.4
Filter
 12345
ND00%25% 6.2%1.6%CAP
 IIIIIIIVV
EffectCLEARCROSSSNOWFOGGYCLEAR
 ABCDE
ECC3200K4300K5600K6300K8000K
Sensitivity F10 (1080/59.94i) / F11 (1080/50i) typical at 2000 lx (White reflection 89.9%)
S/N 61dB typical (HDTV)
Limiting Resolution 1000TV lines
Modulation Depth 50% or more
Variable Color temperature 2,000~20,000K variable
Electric Shutter 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000
Detail Correction Horizonta Boost frequency: 13MHz~22MHz (HDTV)
Gamma OFF,0.35,0.4,0.45
Gain -6,-3, 0, +3, +6, +9, +12, +18dB
Operating Temperature -20°C to +45°C (-4°F to -113°F)
Operating Humidity 30% to 90% (non-condensing)
Operating Voltage DC +11 to +16V
Power Consumption Approx. 20W (without FA)
Weight 4.5Kg with FA (9.92 lbs )
Dimensions Approx W138.5 x H270 xD337 mm, (excluding protrusions,with FA)
(W5.45 x H10.63 x D13.27inch)
Input signals
External Sync Signal SYNC 0.6Vp-p ±6dB 75ohm BNC type 1ch
Audio Signal -60 to +4dB(Variable)/ -20dB (Fixed),XLR type 2ch (600ohm balanced)
Intercom Signal XLR type or 110 type 2ch
Video Trunk HD-SDI BNC 1ch (Option)
*Option for FA-97 and BS/CCU must support Video Trunk.
*Not avaialble with FA-55
Output signals
Analog Video Signal R, G, B D-Sub CN 1ch (for System Expander)
HD SDI Signal Serial Digital 75 ohm 1ch
Q-TV Signal VBS signal 1ch Standard
VBS signal 2ch *Option for FA-97 and BS/CCU must support 2 channels of QTV.
AUX OUT Signal VBS signal 1ch (QTV-1, QTV-2, or Main video selectable by menu)
* Available with FA-55 only.
* QTV-2 can not be selected if BS/CCU does not support 2 channels of QTV.
MON Video Signal VF / RET / MON (MENU Selection) Serial Digital 75 ohm BNC 1ch
or VF / RET / MON / HD-QTV (MENU Selection)
Serial Digital 75 ohm BNC 1ch (Factory Option)
*FA-97+CCU-970M should be needed for HD-QTV output.
*Optional HD-QTV(Trunk) module should be installed in the CCU.
HD QTV Serial Digital 75 ohm 1ch (Option)
*FA-97+CCU-970M are needed for HD-QTV output.
*Optional HD-QTV(Trunk) module must be installed in the CCU
Intercom Signal 0 dBs 4ch (ENG/PROD/PGM1/PGM2), XLR Type or 110 Type CN
DC OUT +12VDC 500mA (max), 4-pin type 1ch
Ikegami HDK-79GX

Ikegami HDK-79GX

16-bit Full Digital HDTV Portable Camera System
Cena Zapytaj o cenę!


Next generation 2.5 Mega pixel high performance CMOS sensors
The camera employs 2.5 Mega pixel 2/3-inch CMOS image sensors, achieving superior quality HDTV video with horizontal resolution of 1000TVL, SNR of 60dB or more, and sensitivity of F11.
Native Multi-format
The CMOS sensors support progressive and interlace readout with standard HDTV formats including 1080i/59.94, 1080i/50, 720p/59.94 and 720p/50.

3G Upgrade Path
The camera supports 1080p/59.94 4:2:2, 1080p/50 4:2:2, 1080i/59.94 4:4:4, and 1080i/50 4:4:4 3G HDTV formats by software upgrade. (Option)
24p Upgrade Path
The camera can also be software upgraded to support 1080p/23.98, 1080p/23.98psf, and 1080i/59.94 with 2-3 pulldown.

Newly developed FPGA DSP
High density 45nm rule FPGA are employed for the digital video processing for superb picture quality. And the DSP includes custom gamma curves (cine gamma).
Lens Aberration Correction function
A Lens Aberration Correction function is newly incorporated for minimizing the loss of resolution and colored edges caused mainly by lens chromatic aberration.

Camera Operator Assist Functions
The HDK-95C camera head incoporates a camera operator assist function to aid the operator finding correct focus. The viewfinder detail (VF DTL) function allows the camera operator to increase the detail edges to the viewfinder video for easy focusing.
HD SDI Trunk
When the camera is operating with FA-97 fiber adaptor and CCU-970 or BS-97, the system allows 3G (1.5G x2) transmission from the camera head to the CCU. With the camera operating in 1.5G, then a second external 1.5G video can be transmitted to the CCU as a video trunk channel. For POV or 3D applications, this will reduce the cables which need to be run. (Option)

Two HD-SDI outputs from the camera head
Two HD-SDI output signals (1.5G) are selectable between Camera, VF, RET and MON (monitor) for external monitoring at the camera head.
Two Channels QTV
Two channels of QTV output (VBS) are available for prompter and external monitoring purposes. (Option)
* BS/CCU must support two channels of QTV
* This function is available with FA-97.

HD SDI QTV Channel
When configured with FA-97 and CCU-970, the HDK-95C includes an HD SDI QTV channel, in addition to the two channels VBS QTV.
Docking style camera body
With a docking style camera body, either an FA (Fiber Adaptor) or TA (Triax Adaptor) can be mounted depending on the use. A new lower profile and lower weight improve the manuverability for shoulder use.

Ikegami HDK-95C

Ikegami HDK-95C

Full Digital HDTV Portable CMOS Camera System
Cena Zapytaj o cenę!
The HDK-970A/970AP is the studio type HDTV camera system, incorporating a newly developed mass memory type FPGA, 45nm design rule, with 16-bit full digital processing and 3G transmission to achieve the highest possible picture quality.

Video processing technology to maximize the benefit of 16-bits
This camera is designed from the start based on 16-bit A/D and matching 16-bit DSP to maximize the benefits of high bit quantization. Especially for the dark areas of the picture, the higher gradation for gamma and other circuits improves the reproduction, providing for more natural color in the shadow areas of the picture.
Newly developed 2.3 Mega pixel progressive sensors
New 2/3-inch 2.3 Mega pixel 1080 progressive CCDs are employed to support not only the usual 1080i 59.94/50Hz 4:2:2,720p 59.94/50Hz 4:2:2 1.5G formats, but also 3G formats such as 1080p 59.94/50Hz 4:2:2 and 1080i 59.94/50Hz 4:4:4. Furthermore, 1080i(119.88/100Hz), 1080p(29.97/25Hz)are available as an option. The HDK-970AP adds support for the 1080p(23.98Hz) format.

Newly developed FPGA
Using mass memory type FPGA,45nm design rule, the video signals are digitized with 16-bit A/D conversion to achieve the highest possible picture quality.
3Gbps high bit-rate video output
The camera supports 3G-SDI 1080p (59.94/50Hz) wide-band video output as a standard feature for higher picture quality. The single and dual link output is available with CCU-970/BS-97 camera control unit/base station supporting 3G-SDI signal

Multi-format
The camera supports various HDTV formats of 1080p (59.94/50Hz), 1080i (59.94/50Hz 4:2:2, 4:4:4), 1080i (119.88/100Hz), 1080p (29.97/25Hz) and 720p (59.94/50Hz), achieving flexible picture representation. * 1080i (119.88/100Hz), 1080p (29.97/25Hz) are option. Furthermore, 23.98P format is also available with the model HDK-970AP/ HDK-97AP.
2 times slo-motion (1080i 119.88/100Hz)
Switchable for live and slo-motion picture with one camera. It is possible to get a slo-motion picture without changing the camera position. (Option)
*The simultaneous output for live and 2 times slo-motion picture is now under development.

Native support for 23.98P
The camera supports not only 23.98Psf, but also 23.98P in native (HDK-970AP/HDK-97AP)
Custom Gamma function
Various kinds of gamma curve can be flexibly set by uesrs.

Camera Operator Assist Functions
There are two types of camera operator assist functions incorporated in the HDK-970A/AP camera head. The viewfinder detail(VF DTL) function allows the camera operator to increase the detail edges to the viewfinder video for easy-focusing. In addition, the Quick EZ Focus (Focus Assist) function is newly incorporated useful tool, providing very distinct enhancement to the viewfinder edge signal to enable the camera operator to make critical focus adjustment.
Digital Extender
The HDK-970A/AP features the Digital Extender function that instantly goes up to 4x to enlarge the image at the center of shot without any loss in image sensitivity.

Lens Aberration Correction function
The Lens Aberration Correction function is newly incorporated for minimizing the blur and colored edges caused mainly by lens chromatic aberration.
Variable Color Temp. function
The Variable Color Temp. function enables the camera operator to variably control the color temperature from 2,000K to 20,000K for more precise adjustment at ease.



Image Sensors 2/3-inch 2.3 million pixel AIT Progressive CCD Sensors
Optical System 2/3-inch, RGB prism, f1.4
Sensitivity F10 at 2000lx (in 1080i/59.94
S/N 62dB (in 1080i/59.94) (Typical)
Modulation Depth 50% or more (800TV lines, 27.5MHz)
Limiting Resolution 1000TV lines (in 1080i/59.94)
Dimensions W315 x H328 x D398mm (excluding VF)
Weight Approx. 24Kg
Ambient Temperature -20℃~+45℃(-4°F~ -113°F)
Relative Humidity 30% ~ 90% (Non-condensing)
Operating Voltage AC100/110/117/220/240V ±10%
Filter
 12345
NDCAP100%25%6.2%1.6%
 ABCDE
CCCROSS3200K4300K6300K8000K
Electronic Color Temperature 5600K
Output Format HDK-970A/CCU970 1080p:(59.94Hz or 50Hz) Y, Pb, Pr 4:2:2 Progressive (SMPTE425 Level B)
1080i:(59.94Hz or 50Hz) Y, Pb, Pr 4:2:2 Interlaced
1080i:(59.94Hz or 50Hz ) RGB 4:4:4 Interlaced
720p:(59.94Hz or 50Hz) Y, Pb, Pr 4:2:2 Progressive
1080i:(119.88 Hz or 100Hz) Y, Pb, Pr 4:2:2 Interlaced (Option)
1080p:(29.97Hz or 25Hz) Y, Pb, Pr 4:2:2 Progressive (Option)
1080p:(23.98Hz) RGB 4:4:4 Progressive (Supported by HDK-970AP)
1080psf:(23.98Hz) RGB 4:4:4 Progressive (Supported by HDK-970AP)
1080pd:(23.98Hz) RGB 4:4:4 Progressive (Supported by HDK-970AP)
1080p:(23.98Hz) Y, Pb, Pr 4:2:2 Progressive (Supported by HDK-970AP)
1080psf:(23.98Hz) Y, Pb, Pr 4:2:2 Progressive (Supported by HDK-970AP)
1080pd:(23.98Hz) Y, Pb, Pr 4:2:2 Progressive (Supported by HDK-970AP)
480i:(59.94Hz) Y, Pb, Pr 4:2:2 Interlaced
576i:(50Hz) Y, Pb, Pr 4:2:2 Interlaced
Gain -3dB, 0dB, +3dB, +6dB, +9dB, +12dB
Input Signals HDK-970A
Video Signals External Sync Signal: SYNC 0.6Vp-p ±6dB 75ohm BNC CN 1ch (BB/PS Signal)
Audio Signal: -60dB ~ +4dB (Variable) / -20dB (Fixed) XLR CN 2ch (600 ohm Balanced)
Intercom Signal : XLR Type or 110 Type CN 2ch
Trunk Signal : HD-SDI BNC 1ch (Factory option)
(This option is available when operated in 1.5G)
Output Signals HDK-970A
Video Signals 3G-SDI/HD SDI Signal : Serial Digital 75 ohm BNC 1ch
Q-TV Signal : HDTV: HD-SDI BNC 1ch (CCU-970 option), 75 ohm VBS 1ch (2nd QTV is factory option) (59.94Hz), 75 ohm VBS 1ch (50Hz)
MON Video Signal (1.5G) : VF / RET / MON / HD-QTV (MENU Selection) Serial Digital 75 ohm BNC 1ch
Ikegami HDK-970A/AP

Ikegami HDK-970A/AP

16-bit Full Digital 3G HDTV Camera System
Cena Zapytaj o cenę!
16-bit full digital processing and 3G transmission for highest picture quality.

Next Generation High Speed Video Processor, AXII
Ikegami has developed a new processing engine, AXII, for our next generation HD, 4K, and 8K cameras. This ASIC can perform high speed processing of super high resolution video signals in various formats and frame rates. The HDK-97A utilizes this new processor, making it possible to deliver high quality, high reliability and low power consumption. The camera is also capable of 16-axis color correction and an improved focus assist function.
S/N ratio of 62dB (Typical)
Taking full advantage of its excellent sensors and video circuits, the HDK-97A offers superb high quality, natural looking pictures with 1000 TV lines of horizontal resolution, F10 sensitivity, and 62dB S/N ratio in HDTV (1080i59.94).

Newly developed 2.3 Mega pixel progressive sensors
New 2/3-inch 2.3 Mega pixel 1080 progressive CCDs are employed to support not only the usual 1080i 59.94/50Hz 4:2:2, 720p 59.94/50Hz 4:2:2 1.5G formats, but also 3G formats such as 1080p 59.94/50Hz 4:2:2 and 1080i 59.94/50Hz 4:4:4. Furthermore, 1080i(119.88/100Hz), 1080p(29.97/25Hz) are available as an option. The HDK-97AP adds support for the 1080p(23.98Hz) format.
Video processing technology to maximize the benefit of 16-bits
This camera is designed from the start based on 16-bit A/D and matching 16-bit DSP to maximize the benefits of high bit quantization. Especially for the dark areas of the picture, the higher gradation for gamma and other circuits improves the reproduction, providing for more natural color in the shadow areas of the picture.

HD SDI Trunk (Option)
When the camera is operating in a conventional 1.5G format, a second 1.5G video from an external source can be transmitted to the CCU as a video trunk channel. For POV or 3D applications this will reduce the cables which need to be run.
Docking style camera body
With a docking style camera body, either an FA (Fiber Adaptor) or TA (Triax Adaptor) can be mounted depending on the use.

Camera Operator Assist Functions
There are two types of camera operator assist functions incorporated in the HDK-97A/AP camera head. The viewfinder detail(VF DTL) function allows the camera operator to increase the detail edges to the viewfinder video for easy-focusing. In addition, the Quick EZ Focus (Focus Assist) function is newly incorporated useful tool, providing very distinct enhancement to the viewfinder edge signal to enable the camera operator to make critical focus adjustment.
Digital Extender
The HDK-97A/AP features the Digital Extender function that instantly goes up to 4x to enlarge the image at the center of shot without any loss in image sensitivity.

Simulcast
Using a down converter and up converter incorporated in the CCU as standard, both HDTV and SDTV signals are provided simultaneously from the CCU. And the CCU offers not only the usual 1080i 59.94/50Hz 4:2:2 1.5G signal outputs, but also 3G outputs like 1080p 59.94/50Hz 4:2:2 and 1080i 59.94/50Hz 4:4:4. (Option)




■Output Format HDK-97A / CCU970
1080p:(59.94Hz or 50Hz) Y, Pb, Pr 4:2:2 Progressive (SMPTE425 Level B)
1080i:(59.94Hz or 50Hz) Y, Pb, Pr 4:2:2 Interlaced
1080i:(59.94Hz or 50Hz ) RGB 4:4:4 Interlaced
1080i:(119.88 Hz or 100Hz) Y, Pb, Pr 4:2:2 Interlaced (Option)
1080p:(29.97Hz or 25Hz) Y, Pb, Pr 4:2:2 Progressive (Option)
720p:(59.94Hz or 50Hz) Y, Pb, Pr 4:2:2 Progressive
720p:(119.88Hz or 100Hz)Y, Pb, Pr 4:2:2 Progressive (Option)
1080p:(23.98Hz) Y, Pb, Pr 4:2:2 Progressive (Supported by HDK-97AP)
480i:59.94Hz Y, Pb, Pr 4:2:2 Interlaced
576i:(50Hz) Y, Pb, Pr 4:2:2 Interlaced
■Image Sensors 2/3-inch 2.3 million pixel AIT CCD Sensors
■Optical System 2/3-inch, RGB prism, f1.4
■Lens Mount BTA- S1005B
■Input Signals
HDK-97A External Sync Signal : SYNC 0.6Vp-p ±6dB 75ohm BNC CN 1ch (BB/PS Signal)
Audio Signal : -60dB ~ +4dB (Variable) / -20dB (Fixed) XLR CN 2ch (600 ohm Balanced)
Intercom Signal : XLR Type or 110 Type CN 2ch
CCU-970
HDTV System External Genlock Signal : PS(1Vp-p) or SYNC(0.6Vp-p±6dB) 75 ohm bridged, 1ch (HDTV/SDTV auto detect)
Return Video Signal : 75 ohm Single End 3G-SDI/HD-SDI (common use) 4ch
HD Q-TV Signal : Y, Pb, Pr 4:2:2 Serial Digital 75 ohm Single End BNC 1ch (Factory Option)
SDTV System Return Video Signal : 75 ohm Single End SD-SDI/VBS (common use) 4ch
* SDTV Return is not available when optional HD-QTV(Trunk) module is installed.
External Genlock Signal : VBS(1Vp-p) or BBS, BBS+10Field ID 75 ohm bridged, 1ch (HDTV/SDTV auto detect)
Q-TV Signal : 75 ohm Single End VBS 2ch
Intercom/Tally Intercom (ENG/PROD) : (4-Wire or Clearcom or RTS)
4-Wire : 0dBm 600 ohm 2ch
Clearcom : -15dBs 200 ohm 2ch
RTS : 0dBm 200 ohm 2ch
Tally : R/G 2ch MAKE/POWER selectable
Program Sound : 0dBs 600 ohm/10K ohm switchable 2ch
■Output Signals
HDK-97A
Video Signals Analog Signal : R,G,B D-Sub SE CN 1ch
3G-SDI/HD SDI Signal : Serial Digital 75 ohm BNC 1ch
Q-TV Signal : 75 ohm VBS 1ch (2nd QTV is factory option) (59.94Hz),
75 ohm VBS 1ch (50Hz)
MON Video Signal (1.5G) : VF / RET / MON (MENU Selection) Serial Digital 75 ohm BNC 1ch,
VF / RET / MON / HD-QTV (MENU Selection) Serial Digital 75 ohm BNC 1ch (Factory Option),
*Optional HD-QTV(Trunk) module should be installed in CCU.
Intercom Signal : 0 dBs 4ch (ENG/PROD/PGM1/PGM2) XLR Type or 110 Type CN
CCU-970
HDTV System 3G-SDI/HD SDI Signal : Serial Digital 75 ohm BNC 2ch 2 outputs per ch(MENU SELECTION)
WFM Signal : Serial Digital Signal SDI 75 ohm BNC 2ch,
Ch1 : 3G-SDI / DUAL-LINK(A) / HD-SDI / SD-SDI(MENU SELECTION),
Ch2 : DUAL-LINK(B) / HD-SDI / SD-SDI / SD Analog(MENU SELECTION)
SDTV System 3G-SDI/HD-SDI PM Signal : Serial Digital 75 ohm BNC 2ch
VBS/SD-SDI Signal : Serial Digital and VBS 75 ohm BNC 2ch each
WFM Signal : Ch1 : Serial Digital 75 ohm BNC 1ch *VBS Output is not available(MENU SELECTION),
Ch2 : Serial Digital or VBS 75 ohm BNC 1ch(MENU SELECTION)
SD-SDI/VBS PM Signal : Serial Digital or VBS 75 ohm BNC 2ch(MENU SELECTION)
Phase Reference Signal : 75 ohm SINGLE END ANALOG 1ch,,
HDTV: Tri-Sync(0.6Vp-p) / SDTV: HV(2Vp-p) (Menu Selection)
Audio Signal Mic : 0dBm XLR-3 (600 ohm Balanced analog) 2ch
Digital Audio : 75 ohm Digital Format BNC 1ch 48KHz Sampling, 24bit Pro, 2-pair ch's (AES3 Compliant)
Intercom/Tally Intercom (ENG/PROD) : (4-Wire or Clearcom or RTS)
4-Wire : 0dBm 600 ohm 2ch
Clearcom : -15dBs 200 ohm 2ch
RTS : 0dBm 200 ohm 2ch
Tally : R/G 2ch,OPEN(OFF)/GND(ON) 50mA (max)
■Filter
 12345
NDCAP100%25%6.2%1.6%
 ABCDE
CCCROSS3200K4300K6300K8000K
■Electronic Color Temperature 5600K
■Ambient Temperature -20℃~+45℃(-4°F~ -113°F)
■Operating Voltage HDK-97A : +11~16V
CCU-970 : AC100/110/117/220/240V ±10%
■Weight HDK-97A : Approx 4.5kg (9.9lbs) (Head + FA)
CCU-970 : Approx 28kg (61.8lbs) (in standard configuration)
■Dimensions HDK-97A : W125 x H215 x D350mm, (W4.92 x H8.64 x D13.78 inches)
CCU-970 : W483 x H133 x D454mm, (W19.02 x H5.24 x D17.87 inches)
Performance
■Sensitivity F10 at 2000lx (in 1080i/59.94)
■S/N 62dB (in 1080i/59.94) (Typical)
■Limiting Resolution HDTV System 1000TV lines (in 1080i/59.94)
■Video Frequency Response (CCU Output) Y Output Signal (4:2:2)
Below 60Hz:Falling, 60Hz ~ 30MHz:within±1.0dB, Over 30MHz:Falling
Pb, Pr Output Signal (4:2:2)
Below 30Hz:Falling, 30Hz ~ 15MHz:within±1.0dB, Over 15MHz:Falling
R,G,B Output Signal (4:4:4)
Below 60Hz:Falling, 60Hz ~ 30MHz:within±1.0dB, Over 30MHz:Falling
■Audio Frequency Response (CCU Output) Mic-1/2 Output
Below 100Hz:Falling, 100Hz ~ 20KHz:within±1.0dB, Over 20KHz:Falling
Intercom Output
Below 100Hz:Falling, 100Hz ~ 10KHz:within±1.0dB, Over 10KHz:Falling
■Detail Correction Vertical 5 lines
Horizontal Boost frequency: 13MHz~24MHz (HDTV)
■Gamma OFF, 0.35, 0.4, 0.45
■Gain -3dB, 0dB, +3dB, +6dB, +9dB, +12dB
■Power Consumption HDK-97A Camera Head: TBA 2-inch VF: 6W
CCU-970 Approx 110VA (CCU only),
400VA or less (incl power for camera with cable loss)
Ikegami HDK-97A

Ikegami HDK-97A

16-bit Full Digital 3G HDTV Portable Camera System
Cena Zapytaj o cenę!
4K Converter Board
Slot in BS-98 and CCU-980: This board provides 4K output from a 2K source. It replaces the V OUT board of an Ikegami base station or camera control unit. Existing BS-98 or CCU-980 models can be upgraded without needing modification. A camera head is required to support the upscaling process.


Sample Video:

produced by VIDEO STAFF.Co.,LTD.
Lenses: FUJIFILM Corporation ZK Light Weight Zoom Lens: ZK4.7x19 / ZK3.5x85, Carl Zeiss Co.,Ltd. Compact Prime CP.2 Lens : CP.2 15 mm/T2.9 / CP.2 35 mm/T1.5 Super Speed

Scanning System 1080p/59.94/29.97, 1080p/50/25, 1080i/59.94/50, 1080psf/29.97, 1080psf/25,1080p/23.98, 1080psf/23.98, 1080pd/23.98, 720p/59.94/50
Sensitivity T11 at 2000 lx (1080p/29.97)
S/N Ratio 64dB (1080p/29.97)
Dynamic Range 1200%
Gain Step Gain:-6, -3, 0, +3, +6, +9, +12dB
Variable:±6dB
Motorized ND filter
  1 2
ND Clear 0D1.2(1/16)
Electrical Color Filters
 A B C D E
ECC 3200K 4300K 5600K 6300K 8000K
Electrical Shutter 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000
Operating Voltage Range -20℃ ~ +45℃
Ambient Temperature Operating -20℃ ~ +45℃
Storage -30℃ ~ +60℃
Dimensions W179 x H288 x D446 mm
Weight 9.0Kg (HDK-97ARRI+FA-97)
Ikegami HDK-97ARRI

Ikegami HDK-97ARRI

Super 35mm Format HDTV Camera System
Cena Zapytaj o cenę!
End-to-end Full Digital 3G HDTV Camera System. Employs high performance CMOS image sensors for superb picture quality

Next generation 2.5 Mega pixel high performance CMOS sensors
The camera employs 2.5 Mega pixel 2/3-inch CMOS image sensors, achieving superior quality HDTV video with horizontal resolution of 1000TVL, SNR of 60dB or more, and sensitivity of F11.
Native Multi-format
The camera supports various kinds of native HDTV formats including 1080i/59.94, 1080i/50, 720p/59.94, 720p/50, 1080p/29.97, and 1080p/25. And it also supports 1080p/59.94 4:2:2, 1080p/50 4:2:2, 1080i/59.94 4:4:4, and 1080i/50 4:4:4 3G HDTV formats.

Newly developed FPGA DSP
High density 45nm rule FPGA are employed for the digital video processing, including operation of the camera at dual rate speed for 60p and 2x slo-motion. The DSP includes custom gamma curves (cine gamma).
Native support for 23.98P
The camera supports not only 23.98pSF, but also native 23.98p and 1080i with 2-3 pulldown. (Option)

2x Slo-Motion (1080i 119.88 / 100Hz)
Switchable for live and slo-motion picture with one camera, making it possible to get slo-motion picture without changing the camera position. (Option)
HD SDI Trunk
When the camera is operating in a conventional 1.5G format, a second 1.5G video from an external source can be transmitted to the CCU as a video trunk channel. For POV or 3D applications this will reduce the cables which need to be run. (Option)

Two Channels QTV
Two channels of QTV output (VBS) are available at the camera for prompter and external monitoring purposes. *Two channel QTV is not available operating at 720P/50Hz. (Option)
Two HD-SDI outputs from the camera head
Two HD-SDI output signals (1.5G) are selectable between Camera, VF, RET and MON (monitor) for external monitoring at the camera head.

Docking style camera body
With a docking style camera body, either an FA (Fiber Adaptor) or TA (Triax Adaptor) can be mounted depending on the use. A new lower profile and lower weight improve the manuverability for shoulder use.


Ikegami HDK-97C

Ikegami HDK-97C

Digital 3G HDTV Portable CMOS Camera System
Cena Zapytaj o cenę!
The camera employs 2.6 Mega pixel 2/3-inch CMOS image sensors, achieving superior quality HDTV video with horizontal resolution of 1000TVL, SNR of 62dB or more, and sensitivity of F11.

Newly Developed High Performance Full HD 2/3-inch CMOS Sensors
The HDK-99 utilizes three 2/3-inch 2.6 mega pixel CMOS sensors, each capable of capturing full HD 1920 x 1080 resolution images and a wide dynamic range of more than 600%, and giving you an excellent sensitivity of F11 (60Hz) / F12 (50Hz), high signal-to-noise ratio and modulation depth.
Next Generation High Speed Video Processor, AXII
Ikegami has developed a new processing engine, AXII, for our next generation HD, 4K, and 8K cameras. This ASIC can per form high speed processing of super high resolution video signals in various formats and frame rates. The HDK-99 utilizes this new processor, making it possible to deliver high quality, high reliability and low power consumption. The camera is also capabile of 16-axis color correction and an improved focus assist function.

Multi-format
The camera supports various HDTV formats of 1080p (59.94/50Hz), 1080i (119.88/100Hz), 1080p (29.97/25Hz) and 720p (59.94/50Hz), achieving flexible picture representation.
2 times slo-motion (1080i 119.88/100Hz)
Switchable for live and slo-motion picture with one camera. It is possible to get a slo-motion picrure without changing the camera positon. (Option)

Supports high-band 3G-SDI (1080p59.94/50Hz) video output
The camera supports 3G-SDI 1080p (59.94/50Hz) wide-band video output as a standard feature for higher picture quality. The single and dual link output is available with CCU-980/BS-98 camera control unit/base station supporting 3G-SDI signal.
16-Axis Color Correction
The color matrix function enables precise color adjustment for all occasions. 16 axes of the color gamut can be fine tuned in both hue and saturation. This function works in real time and is extremely beneficial for live multi-camera applications.

HDR (High Dynamic Range)
The camera provides an HLG (Hybrid Log Gamma) mode, conforming to ITU-R BT.2100 which is an international standard for HDR. It is now possible to expand the range represented f rom dark to bright, providing superb bright pictures with High Dynamic Range, and also achieves r ich colors with wide color gumut. Hybrid Log-Gamma and various kinds of gamma curve can be flexibly set by users.
4K ready
Slot in BS-98 and CCU-980: Optional board provides 4K output from a 2K source.



Specifications
HDK-99
Signal Format 1,080p (59.94/50 Hz), 1,080i (119.88/100 Hz), 1,080i (59.94/50 Hz), 720p (59.94/50 Hz), 1,080p (29.97/25 Hz), 1,080p (23.98 Hz)
Image Sensor 2/3-inch 2.6 million pixel 3CMOS
Optical System 2/3-inch, R,G,B 3 prism, F1.4
Lens Mount B4 mount bayonet
Filter
 12345
 CAP100%25%6.2%1.6%
  ABCDE
 CROSS3200K4300K6300K8000K
Ambient Temperature -20°C to +45°C (-4°F to 113°F)
Relative Humidity 30% to 90% (Non-condensing)
Operating Voltage +11 to 16V
Weight approx. 4.9kg (10.8lbs) (Camera Head + FA, excluding VF)
Dimensions W138.5 x H270 x D337mm (Camera Head + FA, excluding VF) (W5.5 x H10.62 x D13.25 inch)
Sensitivity 2,000 lux F11 (1,080/59.94i)
S/N Ratio 62dB or more
Limiting Resolution 1000TV lines (in 1080/59.94i)
Electrical Shutter 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000
Modulation Depth 60% at 800TV lines (in 1080/59.94i)
Gamma OFF, 0.35, 0.4, 0.45, Hybrid Log Gamma
Gain -6dB, -3dB, 0dB, +3dB, +6dB, +9dB, +12dB, +18dB
Ikegami HDK-99

Ikegami HDK-99

3G 3-CMOS Full Digital HDTV Camera System
Cena Zapytaj o cenę!
The HDL-23 is a Full Digital and Full Resolution HDTV camera equipped with three high performance progressive CMOS sensors, providing superb color reproduction. The optical block camera head is designed for minimum size and weight allowing use in a wide range of POV applications.
The CCU is DC powered for field use, and the camera system can be controlled by Ikegami’s traditional broadcast remote control panels. Small size, light weight, easy operation and handling make the HDL-23 well suited for applications requiring an ultra-compact HDTV camera.

High Performance Progressive CMOS Sensors
1920 x1080 progressive CMOS sensors are employed to achieve 1000TVL horizontal resolution, F10 sensitivity and 54dB SNR.
Compact and Light Camera Head
The compact and light camera head permits use in various application with easy operation and handling.

Various Output Signals
Not only two HD-SDI outputs, but also other output signals such as DVI, HDMI(Option) are available. And it supports simultaneous outputs for SD VBS and Y/C.
Auto Video Level Control
By synchronized control of Auto Gain and Auto Knee, video maintains the correct level automatically even though lighting conditions change. This feature is beneficial when using compact manual iris C-mount lenses, allowing the iris to be fixed at the best setting for depth-of-focus and sensitivity. The starting gain for AVC can be set at 3dB increments, producing maximum SNR for the each application.

Column Adding
Column adding achieves two times standard sensitivity by using 2 horizontal columns for each pixel. Also, line mix achieves another two times standard sensitivity by using 2 vertical rows. In total four times standard sensitivity can be achieved for applications where high sensitivity is required with some sacrifice in resolution.
ICCP Command Control
The camera supports Ikegami's traditional broadcast control command protocol (ICCP), so our broadcast remote control panels used with other EFP cameras can also be used on this POV camera as a part of the overall broadcast camera control system.



Scanning System CMOS Sensor
Output: Progressive 1920 x 1080 59.94Hz / 50Hz
Aspect Ratio:16:9
Image Sensor Three 1/3-inch CMOS sensors
Optical System RGB Prism
Lens Mount C-Mount
Power requirement +12V DC ±10%
Power consumption Approx. 20W
Control Signal Input Ikegami Protocol
Ambient Temperature 0 to +40°C
Input Signals External Tri-level Sync: 0.6Vp-p / 75 ohm x1ch
*The color frame from down converted output can not be locked.
Output Signals (HDTV) HD-SDI: 1080i/59.94Hz, 50Hz 0.8Vp-p / 75ohm x2ch
DVI: 1920x1080p/59.94Hz, 50Hz x 1ch
HDMI (Option): 1920x1080p/59.94Hz, 50Hz x 1ch
Moving/Still Picture File (Option) Still Picture Output: JPEG 1920 x1080
Transmitting Moving Picture: H.264 (6~12 Mbps)
SDTV (down converted) SD-VBS: 1.0Vp-p / 75 ohm x1ch
SD-Y/C : Y : VS1.0Vp-p / 75 ohm x1ch, C : 0.286Vp-p / 75 ohm
Cable Length 5m *Can be extended to 15m with 10m extension cable.
Dimensions Head: W34 x H40 x D40 mm
CCU: W170 x H58 x D200 mm
Weight Head: Less than 0.1kg
CCU: Less than 3kg
Performance
Sensitivity F10 at 2000lx, 3200K
S/N 54dB
Limiting Resolution 1000TVL
Registration Error Registration Error
Shutter Speed (Rolling Shutter) 1/60 to 1/2000 (59.94Hz)
1/50 to 1/2000 (50Hz)
Ikegami HDL-23

Ikegami HDL-23

Full Digital Subminiature 3 CMOS HDTV Camera
Cena Zapytaj o cenę!
HDL-4500 is a Super High Sensitivity 2/3”3CMOS HDTV Camera, achieved minimum illumination 0.001lux/F1.4 (60fps). It employs the same digital processing LSI(ASIC) as standard broadcast studio cameras, achieving high resolution and accurate color reproduction under day time and normal lighting conditions. With its compact one-piece form factor, the camera is suitable for various POV applications such as a traffic and weather camera, as well as, a wide range of surveillance applications.

Ultra-High sensitivity
It enables acquisition of clear images under starlight (0.001lux/F1.4, 60fps). By employing ND filter, ideal images are acquired even under day time. It is applicable to not only night-time operation but also day- time surveillance.
High quality image
It supports high quality images with S/N56dB.

Digital extender
The built-in digital extender expands the center of picture. The expansion can be selected as 1.5X, 2X, 3X, 4X, 6X, 8X, 10X by the camera menu.
AVC(Auto Video Level Control) function
By synchronized control of Auto Iris, Auto Gain and Servo Filter, the video maintains the same level automatically even though lighting conditions change.

ATW(Auto Tracking White balance) function
In addition to conventional one-push style AWB, an incorporated ATW function adjusts white balance continually for outdoor shooting with color temperature changes.




Scanning System 1080/59.94i, 1080/50i
Image Sensor Three 2/3-inch 1.3 million pixel CMOS (RGB)
Effective Pixels 1280 (H) x 720 (V)
Sensitivity F22 or more at 2,000lx
Minimum Illumination 0.001 lx (value in theory)
F1.4, +78dB gain up, 100% video level)
Optical System 2/3-inch RGB F1.4
Lens Mount BTS S-1005B
Optical Filter
  1234
ND100%25% 6.2%1.6%
Built-in Filter Servo
Electric Color Compensation 3200K / 5600K selectable
Power Requirement DC +11V to +16V
Operating Temperature -10 °C - +45 °C (14 °F -113 °F)
Storage Temperature -20 °C - +60 °C (-4 °F -140 °F)
Operating Humidity 30% to 90% (Non-condensing)
Power Consumption 20W approx.
S/N Ratio 56 dB or more
Modulation Depth 60% or more, at 520TVL, 18MHz (1080i)
Limiting Resolution 700 TVL
Gain -6/0/6/12/18/24/30/36/42/48/54/60/66/72/78dB
Gamma OFF, 0.35, 0.40, 0.45
Electric Shutter 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000
Digital Extender 1.5X, 2X, 3X, 4X, 6X, 8X, 10X
Output Signals (Digital) HD-SDI x 2ch
(SMPTE 292M, 75Ω BNC Connector, UP CN BOX type: 1 ch)
Output Signals (Analog) G,B,R / Y,Pb,Pr selectable 1ch
(Multi-pin Connector)
External Sync Input HDTV: PS 1Vp-p, SYNC 0.6Vp-p
SDTV: VBS 1Vp-p, BBS 0.3Vp-p
Dimensions W90 × H103 × D180mm approx.
(W35.4 x H40.6 x D70.9 inch)
Weight 1.7kg / 3.75lbs. approx.
Ikegami HDL-4500

Ikegami HDL-4500

Super High Sensitivity 3CMOS HDTV Camera
Cena Zapytaj o cenę!
The HDL-45E/E1 is a 3CCD multi-purpose HDTV camera achieving superb picture quality, high stability and excellent reliability with the incorporation of Ikegami’s cutting edge digital technologies.
The camera provides superior picture image with newly developed 2/3-inch 2.3 Mega pixel AIT CCDs, digital processing LSI (ASIC) and the latest 14-bit A/D converters. With its compact one-piece form factor, this camera is suitable for various applications such as a weather camera, news flash camera, POV camera, etc.
The HDL-45E1 adds support for the 1080/24psF and 1080/23.98psF formats.

2/3-inch 2.3 Mega pixel AIT CCDs
2/3-inch 2.3 Mega pixel AIT CCDs are employed to achieve 1000 TVL horizontal resolution, F11 sensitivity, and 56dB SNR. By using 1920x1080 pixel sensors, there is no conversion performed within the camera. The full resolution from the sensors is maintained through to the camera output.
14-bit A/D conversion
14-bit A/D converters provide a precise picture image from dark to highlight areas, maximizing the color gradation and achieving natural color reproduction especially in the dark areas.

Built-in Servo Filter / ECC (Electronic Color Compensation) Filter
The 4-position Optical Filter can be remotely controlled from various remote control panels. Adopting ECC filter (3200k/5600k) gives proper white balance without reducing sensitivity, a benefit under high color temperature but low light conditions such as dawn and dusk. The ND and ECC filter can be independently controlled.
Low Noise Gain up
Employing a low-noise amplifier in the Master gain up circuit eliminates noticeable noise and obtains a better signal-to-noise with high gain. 3dB steps for gain up through +12dB has been realized to obtain the precise sensitivity required for a wide range scene illumination.

Advanced Full Digital Processing ASIC
Incorporating Ikegami’s advanced full digital processing ASIC, precision designed at 0.18um rule, the video signals are digitized with 14-bit A/D conversion and up to 38-bit internal digital process circuits. Digitizing white shading, gamma and other correction process in the camera head achieves superb picture quality and high stability. Chip C4 DSP ASIC, originally developed for HDK-series cameras, provides advanced color reproduction and detail enhancement features, including Skin DTL.
Various External Sync Support
In addition to HDTV PS and Tri-Sync signals, SDTV VBS and BBS signals can be used as an external sync signal for genlock.
*Note: SDTV VBS and BBS signals can not be used for 1080/24psF and 1080/23.98psF.

Full Remote Control
The HDL-45E/E1 has full remote control capability from the complete range of Ikegami remote control panels. With matching pictures, the HDL-45E/E1 works with the same OCPs and control systems as Ikegami’s HDK studio cameras. And the camera supports ISCP (Ikegami Simple Command Protocol) by menu switching for third party camera control such as PC control integrated with the remote pan and tilt system.
ATW (Auto Tracking White balance) Function
In addition to conventional one-push style AWB, incorporating the ATW function adjusts white balance automatically for outdoor shooting with color temperature changes.
* Note: The ATW function is only recommended for outdoor shooting.

Digital Extender
The built-in digital extender expands the center of picture. The expansion can be selected as 1.5X, 2X, 3X, 4X, 6X, 8X, 10X by the camera menu.
* Note: When the digital extender is used, resolution is reduced as the expansion rate is increased.
Column Adding
Column adding achieves four times the standard sensitivity by using 2 horizontal and 2 vertical columns for each pixel. Sensitivity is increased without loosing S/N ratio. The Column Adding function is controlled by the gain up switch, and it is possible to set the operation of column adding by the camera menu.
* Note: Trade off of reduced horizontal and vertical resolution, and increased motion blur for vertical.

Frame Accumulation
Frame Accumulation from 1/15 sec. to a maximum of 4sec. is available, increasing sensitivity up to 120 times without loosing S/N ratio.
*Note: Trade off of increased motion blur and noticeable appearance of white spot pixels as exposure time is increased.
AVC (Auto Video Level Control) Function
By synchronized control of Auto Iris, Auto Gain and Servo Filter, video maintains the same level automatically even though lighting conditions change. Especially for continuous outdoor shooting such as a weather camera application, the camera provides stable video level all day long.
Day Mode: Synchronized Auto Iris and ND Filter control, Night Mode: Continuous digital gain control

3D Application Ready
Built-in Horizontal Flip and Line Delay features to support 3D video production when using a beam split type rig.
Multi format
Supported formats for each model as follows:
HDL-45E: 1080/59.94i, 1080/50i, 1080/29.97psF, 1080/25psF
HDL-45E1: 1080/59.94i, 1080/50i, 1080/29.97psF, 1080/25psF, 1080/24psF, 1080/23.98psF



Scanning System HDL-45E
1080/59.94i, 1080/50i, 1080/29.97psF, 1080/25psF
* psF is the Segmented Frame format
HDL-45E1
1080/59.94i, 1080/50i, 1080/29.97psF, 1080/25psF, 1080/24psF, 1080/23.98psF
* psF is the Segmented Frame format
Image Sensor 2/3-inch 2.3 million pixel AIT CCD
Effective Pixels 1920(H)x1080(V)
Lens Mount BTA S-1005B
Optical Filter (w/Full Servo)
  1 2 3 4
ND 100% 25% 6.2% 1.6%
Electronic Color Compensation 3200K/5600K selectable
Sampling Frequency 74.1758MHz and 74.25MHz
Quantization 14-bit
Power Requirement DC+11~+16V
Operating Temperature -10~+45°C
Storage Temperature -20~+60°C
Operating Humidity 30%~90%(Non-condensing)
Dimensions W90 x H103 xD180mm approx. *Excluding projection
Weight 1.7kg approx
Performance
S/N Ratio -56dB
Modulation Depth 40% or more * at 800TVL, 27.5MHz (1080i)
Limiting Resolution 1000 TVL
GAIN 1080i format
-6,-3, 0, +3,+6,+9,+12,+18,+24,+30,+36,+42,+48,+54dB
1080psF format
-6,-3, 0, +3,+6,+9,+12dB
*Gain-up up to +12dB is available in 1080psF format.
GAMMA OFF, 0. 35, 0.40, 0.45
Minimum Illumination (w/o Frame Accumulation)
0.065 lux * Iris;F1.4,+54dB gain up
100% video level, value in theory
(w/ Frame Accumulation)
0.00054 lux * Iris;F1.4,+54dB gain up
4 sec of frame accumulation, 100% video level, value in theory
Electronic Shutter 1/100, 1/120, 1/250, 1/500,1/1000, 1/2000
* in Electronic Shutter mode
Frame Accumulation 1/15, 1/10, 1/8, 1/6, 1/5, 1/4, 1/3, 1/2, 1s, 2s,4s
* in Frame Accumulation mode
Digital Extender 1.5X, 2X, 3X, 4X, 6X, 8X, 10X
Power Consumption 20W approx
Output Signals HD-SDI x2 ch (SMPTE292M) (75Ω BNC Connector).
*Character can be embedded by camera menu.
G,B,R / Y, Pb, Pr selectable (Multi-pin Connector)
External Sync Input HDTV PS 1Vp-p, SYNC 0.6Vp-p
*±6dB (75Ω BNC Connector)
SDTV VBS 1Vp-p, BBS 0.3Vp-p
*In 1080/24psF, 1080/23.98psF formats, the signal can not be synchronized correctly with SDTV VBS/BBS. HDTV sync signal corresponding with the scan format should be input.
Ikegami HDL-45E/HDL-45E1

Ikegami HDL-45E/HDL-45E1

3CCD-Multiple-purpose HDTV camera
Cena Zapytaj o cenę!


  • HDL-50 series HDTV Native Multi-format capability
    All native 1080/59.94i, 1080/50i, 720/59.94p and 720/50p are available from the camera head. (Sister models, HDL-51/HDL-F51, support native 1080/23.98p format, and HDL-50/HS supports 1080/59.94p format as well.)
    Model Type Format
    HDL-50 Standard Body1080/59.94i, 1080/50i, 720/59.94p, 720p/50p
    HDL-50/HS Dual link 1080/59.94p, 1080/59.94i, 1080/50i, 720/59.94p, 720p/50p
    HDL-51 Standard Body 1080/59.94i, 1080/50i, 720/59.94p, 720p/50p, 1080/23.98p
    HDL-51/HS Dual link 1080/59.94p, 1080/59.94i, 1080/50i, 720/59.94p, 720p/50p, 1080/23.98p
    HDL-F50 Gimbal Body 1080/59.94i, 1080/50i, 720/59.94p, 720p/50p
    HDL-F50/HS N/A Not available
    HDL-F51 Gimbal Body 1080/59.94i, 1080/50i, 720/59.94p, 720p/50p, 1080/23.98p
    HDL-F51/HS N/A Not available
  • Ikegami HDL-50

    Ikegami HDL-50

    One-Piece Full Digital Native Multi-format HDTV Camera
    Cena Zapytaj o cenę!


  • HDL-50 series HDTV Native Multi-format capability
    All native 1080/59.94i, 1080/50i, 720/59.94p and 720/50p are available from the camera head. (Sister models, HDL-51/HDL-F51, support native 1080/23.98p format, and HDL-50/HS supports 1080/59.94p format as well.)
    Model Type Format
    HDL-50 Standard Body1080/59.94i, 1080/50i, 720/59.94p, 720p/50p
    HDL-50/HS Dual link 1080/59.94p, 1080/59.94i, 1080/50i, 720/59.94p, 720p/50p
    HDL-51 Standard Body 1080/59.94i, 1080/50i, 720/59.94p, 720p/50p, 1080/23.98p
    HDL-51/HS Dual link 1080/59.94p, 1080/59.94i, 1080/50i, 720/59.94p, 720p/50p, 1080/23.98p
    HDL-F50 Gimbal Body 1080/59.94i, 1080/50i, 720/59.94p, 720p/50p
    HDL-F50/HS N/A Not available
    HDL-F51 Gimbal Body 1080/59.94i, 1080/50i, 720/59.94p, 720p/50p, 1080/23.98p
    HDL-F51/HS N/A Not available
  • Ikegami HDL-51

    Ikegami HDL-51

    One-Piece Full Digital Native Multi-format HDTV Camera
    Cena Zapytaj o cenę!
    Advanced new CMOS sensors are employed to achieve superb picture quality. CMOS sensors have wide dynamic range and, in principle, no smear. The sensors include significant circuitry within the sensor itself, resulting in a digital video interface between sensor and Ikegami camera DSP, all in a very small device with low power consumption. The CMOS sensor includes native progressive and interlace modes for multi-format HD operation.

    Fully Digitized Circuits
    End-to-end Digital processing has been realized through the use of 0.18 micro meter design rule 3.3 million gate ASIC / Fully digital stream through the camera to the HD-SDI output assures signal integrity, high picture quality, and stable and reliable operation.
    HDTV Native Multi-format capability
    All native 1080/59.94i, 1080/50i, 720/59.94p, 720/50p, and 1080/23.98p are available from the camera head. (1080/23.98p is optional)

    Servo Filter
    The 4-position Optical Filter Wheel is motorized with filter position control at the remote control panel (RM-50B, OCP-300, etc.).
    Lower noise with Gain-up
    Employing a low-noise feedback type amplifier circuit in Master gain up, as well as, providing noise cancel circuits in all video related boards, eliminates noticeable noise and obtains a better signal-to-noise with high gain up.

    ND Filter and Electric Color
    Correction (ECC) Filter Employs optical 4-position ND Filter and ECC Filter (3200K/5600K). By the combination of these filters, the camera can handle all kinds of lighting conditions. AWB mode is available to cover the full range of color temperature.




    Image Sensor 2/3-inch, 2,500,000 pixel CMOS Sensor
    Effective Picture Element 1920(H) x 1080(V)
    Optical System 2/3-inch R,G,B prism optics
    Lens Mount BTA-S1005B
    Operating Formats 1080/59.94i, 720/59.94p, 1080/50i, 720/50p
    (1080/23.98p and 1080/23.98psF are options.)
    Output Signal 2ch HD-SDI
    Video Signal 1ch Analog R,G,B or Y,Pb,Pr selectable
    Reference Signal Input Tri-level HD Sync, 0.6Vp-p or VBS 1Vp-p,BBS 0.3Vp-p
    Sensitivity F11 at 2,000 lux
    S/N 60dB
    Horizontal Resolution 1,000TVL for 1080i Format / 700TVL for 720p Format
    Optical Filter 100%, 25%, 6.2%, 1.6%
    ECC Filter 3200K, 5600K
    Gain Control 0dB, +6dB, +12dB, +18dB, +24dB, +30dB
    Electric Shutter 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000
    Operating Temperature -10°C to +45°C (+14°F to +112°F)
    Operating Humidity 30% to 90% (Non-condensing)
    Power Requiremnent DC+12V (DC+11V to DC+16V)
    Power Consumption 18W or less
    Weight 1.5kg
    Dimensions W90 x H103 x D180mm
    Ikegami HDL-57

    Ikegami HDL-57

    One-Piece Full Digital Native Multi-format 3CMOS HDTV Camera
    Cena Zapytaj o cenę!
    The HDL-F3000 is an Ultra Low-light Multi-Purpose Compact Camera, especially well suited for airborne gyro applications. The camera head is compact and light enough (depth : 80mm / weight:1.0 kg) for use with a telephoto lens where space and weight are limited such as in the gyro ball of a helicopter. It produces color images under ultra low light conditions down to an amazing 0.0068 lx minimum scene illumination (0.000057 lx with Frame Accumulation ON), including under starlight.


    KRTK ABC13
    (HDL-F3000+Shotover M1+Churchill BEAR)

    HDL-F3000 + GSS B512


    Signal Format 1080/59.94i, 1080/50i, 1080/29.97psF, 1080/25psF, 720/59.94p, 720/50p
    Image Sensor Three 2/3-inch 2.6million pixel MOS
    Minimum Illumination 0.0068 lx or less (0.000057 lx with Frame Accumulation ON)
    Optical System 2/3-inch, RGB prism, F1.4
    Lens Mount BTA S-1005B
    Motorized Optical ND Filter
    1 2 3 4
    100% 25% 6.2% 1.6%
    (Optional IR-Pass filter is available)
    Electrical Color Filter 3200/ 4300/6300/ 8000K
    Power Requirement +11VDC to +16VDC (Up to 30m Camera Cable)
    Operating Temperature Camera Head -20 ℃ to +45 ℃ (-4℉ to 113℉)
    CCU -10 ℃ to +45 ℃ (14℉ to 113℉)
    Storage Temperature Camera Head -30 ℃ to +60 ℃ (-22℉ to 140℉)
    CCU -20 ℃ to +60 ℃ (-4℉ to 140℉)
    Dimensions Head W100 x H123 x D80 mm (W3.94 x H4.84 x D3.15 inch)
    CCU W120 x H105 x D180 mm (W4.75 x H4.13 x D7.09 inch)
    Weight Camera Head approx. 1.0 kg (2.2 lbs.)
    CCU approx. 1.5 kg (3.3 lbs.)
    S/N Ratio 64dB or more (1080/59.94i with NR ON)
    Limiting Resolution 1000 TV lines
    Gain -6, -3, 0, 3, 6, 9, 12, 18, 24, 30, 36, 42, 48, 54, 60, 66, 72dB
    Gamma OFF, 0.35, 0.40, 0.45
    Electrical Shutter 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 (Variable Shutter available)
    Frame Accumulation 1/30, 1/15, 1/10, 1/8, 1/6, 1/5, 1/4, 1/3, 1/2, 1, 2
    Digital Zoom x1.1 to 10.0
    Power Consumption Camera Head approx. 9.8W
    CCU approx. 23W
    Output Signal 2ch HD-SDI (SMPTE292M)
    External Sync Input HDTV PS 1Vp-p, Sync 0.6Vp-p
    SDTV VBS 1Vp-p, BBS 0.3Vp-p
    Ikegami HDL-F3000

    Ikegami HDL-F3000

    Ultra Low-light Multi-Purpose Compact Camera
    Cena Zapytaj o cenę!
    This is the evolution of the 62nd EMMY® Award winning Hi-Motion technology.

    3-chip sensor
    The Hi-Motion II camera is equipped with a B4 mount and a 3-chip CMOS sensor block generating native 1920 X 1080 pixels without the need for any adapters.
    Paint Function
    The Hi-Motion II Operation Control Panel (OCP) allows the user flexibility manipulating the camera's image quality, using a look and feel identical to that of standard HD broadcast cameras. With Industry standard Matrix settings and easy colour matching to the other line cameras on the show.

    Flicker Correction
    The Hi-Motion II has implemented the Flicker Correction, so the effect of lighting flicker is reduced in the ultra high speed images.
    Continuous Live Output
    The Hi-Motion II provides continuous live video output. This allows the Hi-Motion II to be used as a standard broadcast line camera, as well as a replay camera.

    Recording during Replay
    The Hi-Motion II allows the users to simultaneously record ultra slow motion images during replay. This allows the users to cue up crucial slow motion imagery without missing any crucial on-field action.
    Operation and Control from EVS
    Hi-Motion II allows the users to operate and control from EVS series at Hyper Motion mode as well as its dedicated controller for record & replay.



    [Camera Head]
    General
    Image Sensor 3x CMOS, 2/3-inch Optical System
    Effective picture elements 1920x1080
    Lens Mount B4 Mount
    View Finder 2-inch B/W viewfinder (standard)
    9-inch LCD color viewfinder (option)
    Operation temperature -15 to +40 degrees C
    Storage temperatue -30 to +60 degrees C
    Memory 96GB (32GB x 3ch)
    Frame rate 24 to 1000 fps, 1fps step
    Recording time 38 sec. (at 300fps)
    Shutter 1 to 100%, 1% step
    Dimensions (W x H x D) 146 x 326 x 456 mm
    Weight 7 Kg (without VF and lens)
    Input/Output connectors
    HD-SDI (Replay) 1x BNC type :1080i or 720p / 59.94
    HD-SDI (Live) 1x BNC type :1080i or 720p / 59.94
    HD-SDI (Monitor/Return) 1x BNC type :Monitor-out or Return-in selectable
    Viewfinder 1x Hirose 20pin
    Accessory DC Output 1x XRL 4pin : DC 12V Output (max.2A)
    Remote 1x Hirose 12pin : for Slow Controller & Optional RS-422
    DC Input 2x Neutrik 3pin : DC11 to 17V
    Lens 1x Hirose 12pin
    Mic input 2x XLR 3pin
    Intercom 1 1x XLR 4pin
    Intercom 2 1x XLR 5pin
    Genlock 1x BNC type : HD Tri-Sync or PS / SD VBS or BBS
    Sync 1x Hirose 6pin : VD (Input/Output), Trigger (Input)
    AUX 1x Hirose 10pin : RET 1&2 (Input), R&G Tally (Output)
    OCP 1x Tajimi 8pin
    J-PAD 1x Hoshiden 9pin
    USB 1x USB (Standard A)
    Hybrid Fibre Connector 1x LEMO 3K or TAJIMI OPS (selectable)
    [CCU]
    General
    Power supply AC 100 / 110 / 117 / 220 / 240 V ±10%
    Power consumption 510VA or less (incl. power for camera & 9”VF with cable loss)
    Operating temperature -0 to +45 degrees C
    Storage temperature -30 to +60 degrees C
    Dimensions (W x H x D) 483 x 133x 454 mm
    Weight 28 Kg
    Output signals
    HD-SDI output ・4x BNC type selectable as below
    ・2x Replay and 2x Live:1080i or 720p / 59.94 or 50Hz
    ・2x Dual Link of Replay or Live:1080p / 59.94 or 50Hz
    ・4x 3G-SDI of Replay or Live:1080p / 59.94 or 50Hz
    HD-SDI PM output 2x BNC type,1080i or 720p / 59.94 or 50Hz
    HD-SDI WFM output 2x BNC type,1080i or 720p / 59.94 or 50Hz
    SYNC output 1x BNC type,HD: Tri-Sync
    Input signals
    HD SDI Return input 4x BNC type, 1080i or 720p / 59.94 or 50Hz
    Reference (Genlock) input 1x BNC type, HD Tri-Sync or PS / SD VBS or BBS
    Audio (MIC) output 2x XLR 3pin: 2ch, 0dBm
    Talkback & Tally Both Engineering & Production Talkback Circuits, with 2 Program Sound Inputs
    Intercom (ENG/PROD) (4-wire or Clearcom or RTS)
    4-wire 0dBm,600Ω,2ch
    Clearcom -15dBs,200Ω,2ch
    RTS 0dBm,200Ω,2ch
    Program sound 0dBs,600 or 10KΩ,2ch
    Tally Red, Green input / output
    Others
    OCP 1x Tajimi 8pin
    Slow REM 1x D-sub 9pin, RS-422
    Data Trunk 1x D-sub 15pin, RS-422
    ARC Net 1x BNC type
    Camera Hybrid Fibre Connector 1x LEMO 3K or TAJIMI OPS (selectable)
    ※Specifications subject to change without notice
    Ikegami Hi-Motion II

    Ikegami Hi-Motion II

    Ultra Slow Motion Camera System
    Cena Zapytaj o cenę!
    The HK-399W/HK-399PAW is a state-of-the-art SDTV system incorporating the industry-first 16-bit A/D converter. It is the ultimate SDTV camera, employing the same ASIC as that of an HDTV camera and an AIT chip that achieves a smear level superior to that of an FIT. With its small, lightweight body and low power consumption, the camera provides superb picture quality under a range of environments.

    16-bit A/D Converter-Forerunner in industry
    Employing 16-bit A/D converter that no one has ever done ensures the improvement of gradation on dark portion (Internal process : up to 38bit). Also knee expand circuit that is incorporated at the first step of digital processing IC restores the linearity on high luminance portion that is lost during prekneeprocess.  This makes it possible to do the linear signal processing at 600% in digital process after pre-knee and it contributes the great improvement of the characteristics such as Knee, & Flare.
    AIT (Advanced Interline Transfer) CCD
    Newly developed AIT (Advanced Interline Transfer) CCD offers high sensitivity of f11 and very low smear levels of -135dB with 100,000 times lighting condition. This figure actually exceeds that of FIT chip.

    Low Power Consumption (HK-399PAW)
    Its power consumption is merely approx. 10W thanks to the newest Digital Process IC and signal processing. This contributes the decrease of internal heat-up inside the camera and the stability of electric parts & its longer lifetime. In comparison with HK-388P (20.5W), the consumption is almost half of that.
    Compact & Light Weight (HK-399PAW)
    The camera is ergonomically designed with low profile for stable on-shoulder operation work. It is possible to keep side angle of view. The shoulder pad is made of non-slip material, and camera weight is only 2.3kg (excluding VF and TA). Prompt Software Update via SmartMedia™

    Data transmission on e-mail
    So far, it needs a time and is rather troublesome when the software version is changed. Updated software for HK-399PAW Camera Head can be sent as data through email etc, so by downloading it on SmartMedia and by slotting it in the camera and downloading, the update can be done promptly, simply and easily with less work!
    0.18μm Digital Process
    Using newly developed digital process IC - almost all signalprocessing can be done with this -designed at 0.18micro m rule, the video signals are digitized up to 38-bit internal digital processing. Full digital processing after preknee ensures stable and reliablepicture quality.

    S/N Ratio -66dB (PAL) / -68dB (NTSC) (Typical)
    Excellent S/N 66dB (PAL) / 68dB (NTSC), impossible figure so far, has been achievable thanks to newly developed CCD signal processing, improvement of Pre-Amp, digitization of remaining analog circuit and adoption of 14bit A/D conversion. Also the D/A converter for Video is 12bit, so not only digital but also analog video out can be hi-quality.
    Various DTL Functions
    New DTL functions are incorporated in addition to conventional Diagonal DTL. FINE DTL, WIDE-BAND-DTL, NEW-SKIN-DTL, CLEAR-VF-DTL (Patent-Pending),/ NEW-SLIM-DTL, VERTICAL-SLIM-DTL (5 LINE-DTL)

    System Expander SE-S500
    For the requirement of same performance as studio type Camera, System Expander SE-S500 is available. This unit can mount large lens and 7" VF. Same operability with conventional studio type camera can be achieved.In case of operation with large lens + 5" VF, the operation can be made without SE-S500 by feeding the power to lens & 5" VF from DC12V CN (Max 2A).




    Image Sensor 16:9 2/3” AIT CCD✕3 (Advanced Interline Transfer)
    Total pixels 520,000 pixels (NTSC), 600,000 pixels (PAL)
    Sensitivity F11 / 2000 lx
    Min. Illumination Approx 0.12 lx (F1.4, +48dB, Video level100% Theoretical level)
    Approx 0.004 lx (+48dB gain + Optional module)
    S/N Ratio NTSC: 68dB (typical), PAL : 66dB (typical)
    Modulation Depth 80% (typical) at 5MHz at 16:9
    H. Resolution 16:9:750TV lines (typical), 4:3 :750TV lines (typical)
    V. Resolution NTSC: 400TV lines/480TV lines (Sup-V ON)
    PAL : 500TV lines/570TV lines (Sup-V ON)
    Dynamic range 650% (Real ability)
    Smear level -135dB (Real ability with 100,000 times measure)
    Sampling Frequency 18.0MHz (DSP Internal Process: 36MHz)
    A/D Conversion 16-bit (DSP Internal : MAX 38bit)
    Gain Selection -3,0,+3,+6,+9,+12,+18,+24,+30,+36,+42,+48dB
    Light Accumulation Yes 1/15s to 1s (Option)
    Full Auto Setup Yes (Full / Level / Quick)
    Black Stretch / Press -11% ~ +11% (10 steps)
    Digital DTL Functions Diagonal/ New Slim/New Skin/soft/Boost/Knee apt/Wide Band/Fine DTL
    DTL Boost Correction 3.0 MHz~6.5 MHz (16:9), 2.2~4.9MHz (4:3) (8 steps)
    Lens File Memory Yes (8 lens)
    Scene File Memory Yes (8 scene)
    Memory Card System Smart Media Card
    Electric Shutter (Preset) NTSC: 1/60 (OFF), 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000
    PAL : 1/50 (OFF), 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000
    Variable Shutter NTSC: 2H (1/7867s)~260H (1/60.5s)
    PAL : 2H (1/7812s)~310H(1/50.4s)
    Lens Mount BTA(HK-399W) /B4(HK-399PAW)
    Optical Filter ND: Clear, 1/4ND, 1/16ND, 1/64ND (Servo Standard)
    ECC : 3200K, 4300K, 6300K, 8000K (Remote Controllable)
    EFF : GCLEAR, CROSS, SNOW CROSS, SOFT FOCUS (Servo Standard)
    Voltage AC100/110/117/220/240 (±10%)
    Power Consumption HK-399W:
    Camera Head Approx.130VA
    Camera Head + BS Approx.270VA HK-399PAW
    Camera Head w/o VF Approx.10W
    Dimensions HK-399W W310 x H410.5 x D380mm
    HK-399PAW W126 x H281 x D170mm
    Weight HK-399W Approx.23kg, HK-399PAW 2.3kg [w/o VF]
    Ambient Temperature -20°C~+45°C
    Ambient Humidity 25%~85% (No condensing)
    Ikegami HK-399W / HK-399PAW

    Ikegami HK-399W / HK-399PAW

    16-bit Full Digital SDTV Camera System
    Cena Zapytaj o cenę!
    The Ikegami PV-7A is a 1/2″ CCD ultra-compact two-piece color camera employing Digital Signal Processing Circuitry. The PV-7A micro-head color camera connects to the CCU via a 3.5m (I 1.4ft.), cable. The PV-7A offers an amazing 480 horizontal TV line resolution for crisp color detail with a minimum low light object sensitivity of 5 Lux (.05 fc), at fl.4. Other features of the Ikegami PV-7A include both standard and Y/C video outputs; Genlock input; Auto White Balance (AWB) circuit for superior color rendition; Auto Electronic Shutter Control (AESC) for use of non-auto iris lenses and a DC-powered CCU for both portable and permanent applications. Some of the Ikegami PV-7A accessories which can be purchased include a selection of micro-size lenses; C-mount adapter for use of standard-type lenses; an AC power pack which allows the PV-7A to be powered from a 120VAC source and more. The Ikegami PV-7A is ideal for all color applications where space and portability are required. The PV-7A can even be utilized for vehicle applications such as school buses, trains, planes and even for police and military applications. The PV-7A’s CCU is so small it can be hidden inside a pocket for covert applications.
    Ikegami PV-7A

    Ikegami PV-7A

    Ultra-Compact Digital Processing Color Video Camera
    Cena Zapytaj o cenę!
